BAL S302 PFN RT 1.00 22/27
The description of the properties can be found in chapter: Setting the display mode during initialization
(numeric mode only).
Property of display field number
Property
Operation mode
1
Decimal Dots
numeric (INT32)
2
Offset
numeric (INT32)
3
Scale Factor
numeric (INT32)
4
Range – Upper bound
numeric (INT32)
5
Range – Lower bound
numeric (INT32)
6
Flags
numeric (INT32)
7
Standard-attribute
numeric (INT32)
8
Text-attribute
alphanumeric (ASCII)
9
out of range-attribute
numeric (INT32)
10
Format – Minimum number of digits
numeric (INT32)
11
Format – Minimum width
numeric (INT32)
12
Divisor
numeric (INT32)
