BAL S302 PFN RT 1.00 8/27
4 Model designation
Model designation
This manual applies to units with the following model designation (x = the 'x's in the model designation
indicate the size and design of the units):
S302-xx/xx/xx-xxx/xx-N0
Unit construction
The following figure shows model type S302-05/10/xx-xxx/xx-xx as example for the other model types.
The front frame of the housing is locked with quick-action releases. When opening the unit the front
frame hinges downward.
The following figure shows the unit when open.
Central
Processing
Unit
Power supply
unit
Display modules
Units with double-sided display show the same information on the front and on the rear side.
