Siel 6kVA - Communication Port Details; USB Port Configuration; Optional Modules; List of Available Options

IV388E Rev. 00
  Installation and user manual
Date of issue: 2015-10-15
Pag. 21 of 28 + FR
MTTR
30min
Isolation resistance
> 2MΩ᧤500Vdc᧥
Isolation intension
2820Vdc᧨ <3.5mA᧨1min
Surge
Meeting IEC60664-1 1.2/50uS+8/20uS 6kV/3kA.
Protection
IP20
Parallel circumfluence
1᧧1≤8%᧨N᧧1≤3%
Parallel equal current
1᧧1≤8%᧨N᧧1≤10%
Appendix 2 communication port definition
USB communication port
1
2
4
3
Definition of Male port᧶
Pin 1 VCC , Pin 2 D-
pin 3 D+ , Pin 4 GND
Application: use UPSilon2000 Power Managementsoftware
Available functions of the USB
■ Monitor UPS power status
■ Monitor UPS alarm info
■ Monitor UPS running parameters
■ Timing off/on setting
Appendix 3 Option
1. Dry contact card
2. SNMP card
3. Parallel card
