Parameters/address space
4
4.1
Measurement types and measuring ranges
The following table describes the measuring range and the temperature coefficients you can
configure for each measurement type:
Table 4- 1 Measurement types and measuring ranges
Measurement type
Measuring range
Temperature coefficient
Deactivated
–
–
Resistor (2-, 3-, 4-wire connection) 150 Ω / 300 Ω / 600 Ω /
3 kΩ / 6 kΩ
–
Resistor (2-wire connection)
PTC
–
Thermal resistor RTD
(3-wire connection)
Climatic / Standard
Cu 10
Cu 0.00427
1
Thermal resistor RTD
(2, 3, 4-wire connection)
Climatic / Standard
Pt 100
Pt 200
Pt 500
Pt 1000
Pt 0.00385 /
Pt 0.003916 /
Pt 0.003902 /
Pt 0.00392 /
Pt 0.00385055
Climatic / Standard
Ni 100
Ni 120
Ni 200
Ni 500
Ni 1000
Ni 0.00618 /
Ni 0.00672
Climatic
2
/ Standard
2
Ni 1000
Ni 0.005
Thermocouple (TC) Type E, N, J, K, L, S, R,
B, T, C, U, TXK (acc. to GOST)
Voltage ±50 mV / ±80 mV /
±250 mV / ±1 V
1
The preset temperature coefficients are valid for Europe.
2
For sensors LG-Ni 1000 from Siemens Building Ltd (Landis & Stäfa).
