Analog input module AI 4xRTD/TC 2-/3-/4-wire HF (6ES7134-6JD00-0CA1)
Manual, 02/2014, A5E03573289-AD
41
6ES7134-6JD00-0CA1
Analog inputs
Number of analog inputs
4
Maximum permissible input voltage for voltage input
(destruction limit)
30 V
Constant measurement current for resistance-type sensor, typ.
2 mA
Cycle time
(all channels), min. Sum of the basic conversion times
and additional processing times
(depending on the parameter
assignment of the activated
channels); an additional cycle is
necessary for cable compensation
for a 3-wire connection
Technical unit for temperature measurement can be set
Yes
Input ranges (rated values), voltages
-1 V to +1 V
Yes; 16 bits incl. sign
Input resistance (-1 V to +1 V)
1 MΩ
-250 mV to +250 mV
Yes; 16 bits incl. sign
Input resistance (-250 mV to +250 mV)
1 MΩ
-50 mV to +50 mV
Yes; 16 bits incl. sign
Input resistance (-50 mV to +50 mV)
1 MΩ
-80 mV to +80 mV
Yes; 16 bits incl. sign
Input resistance (-80 mV to +80 mV)
1 MΩ
Input ranges (rated values), thermocouples
Type B
Yes; 16 bits incl. sign
Input resistance (Type B)
1 MΩ
Type C
Yes; 16 bits incl. sign
Input resistance (Type C)
1 MΩ
Type E
Yes; 16 bits incl. sign
Input resistance (Type E)
1 MΩ
Type J
Yes; 16 bits incl. sign
Input resistance (Type J)
1 MΩ
Type K
Yes; 16 bits incl. sign
Input resistance (Type K)
1 MΩ
Type L
Yes; 16 bits incl. sign
Input resistance (Type L)
1 MΩ
Type N
Yes; 16 bits incl. sign
Input resistance (Type N)
1 MΩ
Type R
Yes; 16 bits incl. sign
Input resistance (Type R)
1 MΩ
Type S
Yes; 16 bits incl. sign
Input resistance (Type S)
1 MΩ
Type T
Yes; 16 bits incl. sign
Input resistance (Type T)
1 MΩ
Type U
Yes; 16 bits incl. sign
Input resistance (Type U)
1 MΩ
