Technical specifications
6.1 Technical specifications
Analog input module AI 4xRTD/TC 2-/3-/4-wire HF (6ES7134-6JD00-0CA1)
46 Manual, 02/2014, A5E03573289-AD
Operational and basic error limits for thermocouples
Error limits for thermocouples
Operational limit for thermocouples (in the entire temperature range, in
relation to the input range)
±1.5 K
Operational limit for type C thermocouples (in the entire temperature
range, in relation to the input range)
1
± 7 K
Basic error limit for thermocouples (operational limit at 25 °C, in relation
to the input range)
±1 K
Basic error limit for type C thermocouples (operational limit at 25 °C, in
relation to the input range)
± 5 K
Overall error limits when using internal compensation
• Operational limit (in the entire temperature range at static thermal
state, ambient temperature change < 0.3 K/min)
2
± 2.5 K
• Basic error limit (operational limit at 25 °C at static thermal state,
ambient temperature change < 0.3 K/min)
3
±1.5 K
1
The indicated error limits apply as of the following temperatures:
Thermocouple type T: -200 °C
Thermocouple type K: -100 °C
Thermocouple type B: +700 °C
Thermocouple type N: -150 °C
Thermocouple type E: -150 °C
Thermocouple type R: +200 °C
Thermocouple type S: +100 °C
2
For thermocouple type C: ± 8 K
3
For thermocouple type C: ± 6 K
Dimension drawing
See manual ET 200SP BaseUnits
(http://support.automation.siemens.com/WW/view/en/58532597/133300)
