Analog Indicator [ODA] - (V2.2)
Code R/W Description Range Register (MB)
L#P1ALI R/W Process 1 Alarm A Limit (%) -3.3 to 103.3 ($0-$0FFF) 40451+30(#-1)
L#P1BLI R/W Process 1 Alarm B Limit (%) -3.3 to 103.3 ($0-$0FFF) 40452+30(#-1)
L#P2ALI R/W Process 2 Alarm A Limit (%) -3.3 to 103.3 ($0-$0FFF) 40453+30(#-1)
L#P2BLI R/W Process 2 Alarm B Limit (%) -3.3 to 103.3 ($0-$0FFF) 40454+30(#-1)
L#P3ALI R/W Process 3 Alarm A Limit (%) -3.3 to 103.3 ($0-$0FFF) 40455+30(#-1)
L#P3BLI R/W Process 3 Alarm B Limit (%) -3.3 to 103.3 ($0-$0FFF) 40456+30(#-1)
L#P4ALI R/W Process 4 Alarm A Limit (%) -3.3 to 103.3 ($0-$0FFF) 40457+30(#-1)
L#P4BLI R/W Process 4 Alarm B Limit (%) -3.3 to 103.3 ($0-$0FFF) 40458+30(#-1)
L#P1ATI R/W Process 1 Alarm A Type
0-3 ($0000-$0003) 40459+30(#-1)
L#P1BTI R/W Process 1 Alarm B Type
0-3 ($0000-$0003) 40460+30(#-1)
L#P2ATI R/W Process 2 Alarm A Type
0-3 ($0000-$0003) 40461+30(#-1)
L#P2BTI R/W Process 2 Alarm B Type
0-3 ($0000-$0003) 40462+30(#-1)
L#P3ATI R/W Process 3 Alarm A Type
0-3 ($0000-$0003) 40463+30(#-1)
L#P3BTI R/W Process 3 Alarm B Type
0-3 ($0000-$0003) 40464+30(#-1)
L#P4ATI R/W Process 4 Alarm A Type
0-3 ($0000-$0003) 40465+30(#-1)
L#P4BTI R/W Process 4 Alarm B Type
0-3 ($0000-$0003) 40466+30(#-1)
L#P1API R/W Process 1 Alarm A Priority
1-5 ($0001-$0005) 40467+30(#-1)
L#P1BPI R/W Process 1 Alarm B Priority
1-5 ($0001-$0005) 40468+30(#-1)
L#P2API R/W Process 2 Alarm A Priority
1-5 ($0001-$0005) 40469+30(#-1)
L#P2BPI R/W Process 2 Alarm B Priority
1-5 ($0001-$0005) 40470+30(#-1)
L#P3API R/W Process 3 Alarm A Priority
1-5 ($0001-$0005) 40471+30(#-1)
L#P3BPI R/W Process 3 Alarm B Priority
1-5 ($0001-$0005) 40472+30(#-1)
L#P4API R/W Process 4 Alarm A Priority
1-5 ($0001-$0005) 40473+30(#-1)
L#P4BPI R/W Process 4 Alarm B Priority
1-5 ($0001-$0005) 40474+30(#-1)
….. ….. ….. ….. …..
(spare) 0 ($0000) 40480+30(#-1)
