Siemens 353 User Manual

Data Mapping UM353-1B
April 2012
6-22
6.3.10 Sequencer Loop I/O Coil Data (1-bit)
Sequencer:
Code
R/W Description Range Coil (MB)
SG0KI0 R Seq. Group 0 (cur. step) masK for Input 0 1/0 01496
...............................................................................................................................................................................
SG0KIF R Seq. Group 0 (cur. step) masK for Input F 1/0 01511
SG0SI0 R Seq. Group 0 (cur. step) State of Input 0 1/0 01512
...............................................................................................................................................................................
SG0SIF R Seq. Group 0 (cur. step) State of Input F 1/0 01527
SG0SO0 R Seq. Group 0 (cur. step) State of Output 0 1/0 01528
...............................................................................................................................................................................
SG0SOF R Seq. Group 0 (cur. step) State of Output F 1/0 01543
................................................................................................................................................................................
................................................................................................................................................................................
SGFKI0 R Seq. Group F (cur. step) masK for Input 0 1/0 02216
...............................................................................................................................................................................
SGFKIF R Seq. Group F (cur. step) masK for Input F 1/0 02231
SGFSI0 R Seq. Group F (cur. step) State of Input 0 1/0 02232
...............................................................................................................................................................................
SGFSIF R Seq. Group F (cur. step) State of Input F 1/0 02247
SGFSO0 R Seq. Group F (cur. step) State of Output 0 1/0 02248
...............................................................................................................................................................................
SGFSOF R Seq. Group F (cur. step) State of Output F 1/0 02263
