Siemens 353 - PCOM Block Status

UM353-1B Data Mapping
April 2012
6-21
6.3.9 PCOM Block Status
Controller/Sequencer
Code
R/W Description Range Coil(MB)
L#INIT_OK R/W 1-INIT_OK 1/0 09101+32(#-1)
L#DFAIL R/W 1-DFAIL 1/0 09102+32(#-1)
L#RESET W 1-RESET 1/0 09103+32(#-1)
L#START W 1-START 1/0 09104+32(#-1)
L#RESTART W 1-RESTART 1/0 09105+32(#-1)
L#HOLD W 1-HOLD 1/0 09106+32(#-1)
L#PCOMP W 1-PCOMP 1/0 09107+32(#-1)
L#ABORT W 1-ABORT 1/0 09108+32(#-1)
L#READY R 1-READY 1/0 09109+32(#-1)
L#RUN R 1-RUN 1/0 09110+32(#-1)
L#HELD R 1-HELD 1/0 09111+32(#-1)
L#DONE R 1-DONE 1/0 09112+32(#-1)
L#ABORTED R 1-ABORTED 1/0 09113+32(#-1)
spare R 1/0 09114+32(#-1)
spare R 1/0 09115+32(#-1)
spare R 1/0 09116+32(#-1)
Code
R/W Description Range Coil(MB)
L#EMERG (EO) R 1-Emerg. Override 1/0 09117+32(#-1)
L#NotAck’dEO R/W 1-EO Not Ack’d 1/0 09118+32(#-1)
L#INTRLK (IK) R 1-INTRLK 1/0 09119+32(#-1)
L#NotAck’d IK R/W 1- IK Not Ack’d 1/0 09120+32(#-1)
L#FAILED (FD) R 1-FAILED 1/0 09121+32(#-1)
L#NotAck’dFD R/W 1- FD Not Ack’d 1/0 09122+32(#-1)
spare R 1/0 09123+32(#-1)
spare R 1/0 09124+32(#-1)
spare R 1/0 09125+32(#-1)
spare R 1/0 09126+32(#-1)
spare R 1/0 09127+32(#-1)
spare R 1/0 09128+32(#-1)
spare R 1/0 09129+32(#-1)
spare R 1/0 09130+32(#-1)
L#NotAck’dPCOM R/W 1-PCOM Evnt Not Ack’d 1/0 09131+32(#-1)
L#ACTIVEPCOM R 1-PCOM Event is Active 1/0 09132+32(#-1)
