Data Mapping UM353-1B
April 2012
6-20
Pushbutton/Switch Indicator [ODP]
Code
R/W Description Range Coil(MB)
L#G1P1 W Group 1 - Press PB1 (**) 1 00296+48(#-1)
L#G1P2 W Group 1 - Press PB2 (**) 1 00297+48(#-1)
L#G1S3 R/W Group 1 - Auto/Man Switch (*) 1/0 00298+48(#-1)
L#G1FS R Group 1 Feedback Status 1/0 00299+48(#-1)
L#G2P1 W Group 2 - Press PB1 (**) 1 00300+48(#-1)
L#G2P2 W Group 2 - Press PB2 (**) 1 00301+48(#-1)
L#G2S3 R/W Group 2 - Auto/Man Switch (*) 1/0 00302+48(#-1)
L#G2FS R Group 2 - Feedback Status 1/0 00303+48(#-1)
L#G3P1 W Group 3 - Press PB1 (**) 1 00304+48(#-1)
L#G3P2 W Group 3 - Press PB2 (**) 1 00305+48(#-1)
L#G3S3 R/W Group 3 - Auto/Man Switch (*) 1/0 00306+48(#-1)
L#G3FS R Group 3 - Feedback Status 1/0 00307+48(#-1)
L#G4P1 W Group 4 - Press PB1 (**) 1 00308+48(#-1)
L#G4P2 W Group 4 - Press PB2 (**) 1 00309+48(#-1)
L#G4S3 R/W Group 4 - Auto/Man Switch (*) 1/0 00310+48(#-1)
L#G4FS R Group 4 - Feedback Status 1/0 00311+48(#-1)
L#G5P1 W Group 5 - Press PB1 (**) 1 00312+48(#-1)
L#G5P2 W Group 5 - Press PB2 (**) 1 00313+48(#-1)
L#G5S3 R/W Group 5 - Auto/Man Switch (*) 1/0 00314+48(#-1)
L#G5FS R Group 5 - Feedback Status 1/0 00315+48(#-1)
L#G6P1 W Group 6 - Press PB1 (**) 1 00316+48(#-1)
L#G6P2 W Group 6 - Press PB2 (**) 1 00317+48(#-1)
L#G6S3 R/W Group 6 - Auto/Man Switch (*) 1/0 00318+48(#-1)
L#G6FS R Group 6 - Feedback Status 1/0 00319+48(#-1)
L#G7P1 W Group 7 - Press PB1 (**) 1 00320+48(#-1)
L#G7P2 W Group 7 - Press PB2 (**) 1 00321+48(#-1)
L#G7S3 R/W Group 7 - Auto/Man Switch (*) 1/0 00322+48(#-1)
L#G7FS R Group 7 - Feedback Status 1/0 00323+48(#-1)
L#G8P1 W Group 8 - Press PB1 (**) 1 00324+48(#-1)
L#G8P2 W Group 8 - Press PB2 (**) 1 00325+48(#-1)
L#G8S3 R/W Group 8 - Auto/Man Switch (*) 1/0 00326+48(#-1)
L#G8FS R Group 8 - Feedback Status 1/0 00327+48(#-1)
* L#GnS3 - reading a "1" indicates a switch position of Auto and reading a "0" indicates Man. Writing a "1" to the
controller will toggle the state of the Auto/Man switch.
** L#GnP1 & L#GnP2 - writing a "1" to the controller will have the same affect as pushing the button on the
faceplate of the controller. If the action of the switch is sustained the switch will change position. If the action is
momentary the switch will close for one scan cycle.
