UM353-1B Data Mapping
April 2012
6-19
Digital Indicator [ODD]
Code R/W Description Range Coil(MB)
L#D0I R Discrete 0 Input 1-ON 0-OFF 1/0 00296+48(#-1)
L#D1I R Discrete 1 Input 1-ON 0-OFF 1/0 00297+48(#-1)
L#D2I R Discrete 2 Input 1-ON 0-OFF 1/0 00298+48(#-1)
L#D3I R Discrete 3 Input 1-ON 0-OFF 1/0 00299+48(#-1)
L#D4I R Discrete 4 Input 1-ON 0-OFF 1/0 00300+48(#-1)
L#D5I R Discrete 5 Input 1-ON 0-OFF 1/0 00301+48(#-1)
L#D6I R Discrete 6 Input 1-ON 0-OFF 1/0 00302+48(#-1)
L#D7I R Discrete 7 Input 1-ON 0-OFF 1/0 00303+48(#-1)
L#D8I R Discrete 8 Input 1-ON 0-OFF 1/0 00304+48(#-1)
L#D9I R Discrete 9 Input 1-ON 0-OFF 1/0 00305+48(#-1)
L#DAI R Discrete A Input 1-ON 0-OFF 1/0 00306+48(#-1)
L#DBI R Discrete B Input 1-ON 0-OFF 1/0 00307+48(#-1)
L#DCI R Discrete C Input 1-ON 0-OFF 1/0 00308+48(#-1)
L#DDI R Discrete D Input 1-ON 0-OFF 1/0 00309+48(#-1)
L#DEI R Discrete E Input 1-ON 0-OFF 1/0 00310+48(#-1)
L#DFI R Discrete F Input 1-ON 0-OFF 1/0 00311+48(#-1)
L#D0S R/W Discrete 0 Status 1-Auto 0-Manual (*) 1/0 00312+48(#-1)
L#D1S R/W Discrete 1 Status 1-Auto 0-Manual (*) 1/0 00313+48(#-1)
L#D2S R/W Discrete 2 Status 1-Auto 0-Manual (*) 1/0 00314+48(#-1)
L#D3S R/W Discrete 3 Status 1-Auto 0-Manual (*) 1/0 00315+48(#-1)
L#D4S R/W Discrete 4 Status 1-Auto 0-Manual (*) 1/0 00316+48(#-1)
L#D5S R/W Discrete 5 Status 1-Auto 0-Manual (*) 1/0 00317+48(#-1)
L#D6S R/W Discrete 6 Status 1-Auto 0-Manual (*) 1/0 00318+48(#-1)
L#D7S R/W Discrete 7 Status 1-Auto 0-Manual (*) 1/0 00319+48(#-1)
L#D8S R/W Discrete 8 Status 1-Auto 0-Manual (*) 1/0 00320+48(#-1)
L#D9S R/W Discrete 9 Status 1-Auto 0-Manual (*) 1/0 00321+48(#-1)
L#DAS R/W Discrete A Status 1-Auto 0-Manual (*) 1/0 00322+48(#-1)
L#DBS R/W Discrete B Status 1-Auto 0-Manual (*) 1/0 00323+48(#-1)
L#DCS R/W Discrete C Status 1-Auto 0-Manual (*) 1/0 00324+48(#-1)
L#DDS R/W Discrete D Status 1-Auto 0-Manual (*) 1/0 00325+48(#-1)
L#DES R/W Discrete E Status 1-Auto 0-Manual (*) 1/0 00326+48(#-1)
L#DFS R/W Discrete F Status 1-Auto 0-Manual (*) 1/0 00327+48(#-1)
L#D0O R/W Discrete 0 Output 1-ON 0-OFF 1/0 00328+48(#-1)
L#D1O R/W Discrete 1 Output 1-ON 0-OFF 1/0 00329+48(#-1)
L#D2O R/W Discrete 2 Output 1-ON 0-OFF 1/0 00330+48(#-1)
L#D3O R/W Discrete 3 Output 1-ON 0-OFF 1/0 00331+48(#-1)
L#D4O R/W Discrete 4 Output 1-ON 0-OFF 1/0 00332+48(#-1)
L#D5O R/W Discrete 5 Output 1-ON 0-OFF 1/0 00333+48(#-1)
L#D6O R/W Discrete 6 Output 1-ON 0-OFF 1/0 00334+48(#-1)
L#D7O R/W Discrete 7 Output 1-ON 0-OFF 1/0 00335+48(#-1)
L#D8O R/W Discrete 8 Output 1-ON 0-OFF 1/0 00336+48(#-1)
L#D9O R/W Discrete 9 Output 1-ON 0-OFF 1/0 00337+48(#-1)
L#DAO R/W Discrete A Output 1-ON 0-OFF 1/0 00338+48(#-1)
L#DBO R/W Discrete B Output 1-ON 0-OFF 1/0 00339+48(#-1)
L#DCO R/W Discrete C Output 1-ON 0-OFF 1/0 00340+48(#-1)
L#DDO R/W Discrete D Output 1-ON 0-OFF 1/0 00341+48(#-1)
L#DEO R/W Discrete E Output 1-ON 0-OFF 1/0 00342+48(#-1)
L#DFO R/W Discrete F Output 1-ON 0-OFF 1/0 00343+48(#-1)
L#PB1 R/W PB1SW Input MD (**) 1/0 08701+16(#-1)
L#PB2 R/W PB2SW Input MD (**) 1/0 08702+16(#-1)
(spares) 08703-08716+16(#-1)
(*) L#DnS - writing a "1" toggles the switch, Reading "1" indicates Auto Status; reading "0" indicate Man status.
(**) L#PB1 & L#PB2 - writing a "1" to the controller will have the same affect as pushing the button on the
faceplate of the controller. If the action of the switch is sustained the switch will change position. If the action is
momentary, the switch will close for one scan cycle. Reading the bits indicates the status of the switch MD input.
