Siemens 353 User Manual

Data Mapping UM353-1B
April 2012
6-12
Sequencer [ODS]
Code
R/W Description Range Register (MB)
L#S001TIM R/W Step 1 Time Period (min) Real 43951+60(#-1)
L#S001AEP R/W Step 1 Analog End Point Real 43953+60(#-1)
L#S002TIM R/W Step 2 Time Period (min) Real 43955+60(#-1)
L#S002AEP R/W Step 2 Analog End Point Real 43957+60(#-1)
L#S003TIM R/W Step 3 Time Period (min) Real 43959+60(#-1)
L#S003AEP R/W Step 3 Analog End Point Real 43961+60(#-1)
L#S004TIM R/W Step 4 Time Period (min) Real 43963+60(#-1)
L#S004AEP R/W Step 4 Analog End Point Real 43965+60(#-1)
L#S005TIM R/W Step 5 Time Period (min) Real 43967+60(#-1)
L#S005AEP R/W Step 5 Analog End Point Real 43969+60(#-1)
L#S006TIM R/W Step 6 Time Period (min) Real 43971+60(#-1)
L#S006AEP R/W Step 6 Analog End Point Real 43973+60(#-1)
L#S007TIM R/W Step 7 Time Period (min) Real 43975+60(#-1)
L#S007AEP R/W Step 7 Analog End Point Real 43977+60(#-1)
L#S008TIM R/W Step 8 Time Period (min) Real 43979+60(#-1)
L#S008AEP R/W Step 8 Analog End Point Real 43981+60(#-1)
L#S009TIM R/W Step 9 Time Period (min) Real 43983+60(#-1)
L#S009AEP R/W Step 9 Analog End Point Real 43985+60(#-1)
L#S010TIM R/W Step 10 Time Period (min) Real 43987+60(#-1)
L#S010AEP R/W Step 10 Analog End Point Real 43989+60(#-1)
(spares) 44991-44009+60(#-1)
Controller [ODA]
Code R/W Description Range Register (MB)
L#Q1MNF
R/W Quickset 1 MIN SCALE Real 43951+60(#-1)
L#Q1MXF
R/W Quickset 1 MAX SCALE Real 43953+60(#-1)
L#Q2MNF
R/W Quickset 2 MIN SCALE Real 43955+60(#-1)
L#Q2MXF
R/W Quickset 2 MAX SCALE Real 43957+60(#-1)
L#Q3MNF
R/W Quickset 3 MIN SCALE Real 43959+60(#-1)
L#Q3MXF
R/W Quickset 3 MAX SCALE Real 43961+60(#-1)
L#Q4MNF
R/W Quickset 4 MIN SCALE Real 43963+60(#-1)
L#Q4MXF
R/W Quickset 4 MAX SCALE Real 43965+60(#-1)
L#P1MNF R Process 1 MIN SCALE Real 43967+60(#-1)
L#P1MXF R Process 1 MAX SCALE Real 43969+60(#-1)
L#P2MNF R Process 2 MIN SCALE Real 43971+60(#-1)
L#P2MXF R Process 2 MAX SCALE Real 43973+60(#-1)
L#P3MNF R Process 3 MIN SCALE Real 43975+60(#-1)
L#P3MXF R Process 3 MAX SCALE Real 43977+60(#-1)
L#P4MNF R Process 4 MIN SCALE Real 43979+60(#-1)
L#P4MXF R Process 4 MAX SCALE Real 43981+60(#-1)
(spares) ($00000000) 43983-44009+60(#-1)
