Data Mapping UM353-1B
April 2012
6-24
Code
R/W Description Range Register (MB)
A3RMN R ATD03 MIN SCALE Real 48401
A3RMX R ATD03 MAX SCALE Real 48403
A3DPP R ATD03 Decimal Point Position 0-5 48405
A3EU R ATD03 Engineering Units 6 ASCII Char 48406
A3YR R ATD03 Year V2.0 (5) 1997- 48409
A3MT R ATD03 Month V2.0 (5) 1-12 48410
A3DY R ATD03 Day V2.0 (5) 1-31 48411
A3HR R ATD03 Hour V2.0 (5) 0-23 48412
A3MN R ATD03 Minute V2.0 (5) 0-59 48413
A3SC R ATD03 Second V2.0 (5) 0-59 48414
A3ST R/W* ATD03 Sample Time x0.01=min 1-48000 48415
A3STC R ATD03 % Sample Time Complete 0-1000 (x.1=%) 48416
A3D1 R ATD03 Data 1 (latest) 0-100% 128-3968 48417
A3D2 R ATD03 Data 2 0-100% 128-3968 48418
A3D3 R ATD03 Data 3 0-100% 128-3968 48419
....................................................................................................................................................................
A3D168 R ATD03 Data 168 0-100% 128-3968 48584
A3D169 R ATD03 Data 169 0-100% 128-3968 48585
A3D170 R ATD03 Data 170 0-100% 128-3968 48586
* Writing to the sample time will reset all data points A3D1 through A3D170 to $0.
A4RMN R ATD04 MIN SCALE Real 48601
A4RMX R ATD04 MAX SCALE Real 48603
A4DPP R ATD04 Decimal Point Position 0-5 48605
A4EU R ATD04 Engineering Units 6 ASCII Char 48606
A4YR R ATD04 Year V2.0 (5) 1997- 48609
A4MT R ATD04 Month V2.0 (5) 1-12 48610
A4DY R ATD04 Day V2.0 (5) 1-31 48611
A4HR R ATD04 Hour V2.0 (5) 0-23 48612
A4MN R ATD04 Minute V2.0 (5) 0-59 48613
A4SC R ATD04 Second V2.0 (5) 0-59 48614
A4ST R/W* ATD04 Sample Time x0.01=min 1-48000 48615
A4STC R ATD04 % Sample Time Complete 0-1000 (x.1=%) 48616
A4D1 R ATD04 Data 1 (latest) 0-100% 128-3968 48617
A4D2 R ATD04 Data 2 0-100% 128-3968 48618
A4D3 R ATD04 Data 3 0-100% 128-3968 48619
....................................................................................................................................................................
A4D168 R ATD04 Data 168 0-100% 128-3968 48784
A4D169 R ATD04 Data 169 0-100% 128-3968 48785
A4D170 R ATD04 Data 170 0-100% 128-3968 48786
* Writing to the sample time will reset all data points A4D1 through A4D170 to $0.
