UM353-1B Data Mapping
April 2012
6-27
Sequencer Time & Analog Configurations
Code R/W Description Range Register (MB)
S001TIM R/W Step 1 Time Period (min) Real 420001
S001AEP R/W Step 1 Analog End Point Real 420003
S002TIM R/W Step 2 Time Period (min) Real 420005
S002AEP R/W Step 2 Analog End Point Real 420007
S003TIM R/W Step 3 Time Period (min) Real 420009
S003AEP R/W Step 3 Analog End Point Real 420011
S004TIM R/W Step 4 Time Period (min) Real 420013
S004AEP R/W Step 4 Analog End Point Real 420015
..........................................................................................................................................................................................
S246TIM R/W Step 246 Time Period (min) Real 420981
S246AEP R/W Step 246 Analog End Point Real 420983
S247TIM R/W Step 247 Time Period (min) Real 420985
S247AEP R/W Step 247 Analog End Point Real 420987
S248TIM R/W Step 248 Time Period (min) Real 420989
S2488AEP R/W Step24 8 Analog End Point Real 420991
S249TIM R/W Step 249 Time Period (min) Real 420993
S249AEP R/W Step 249 Analog End Point Real 420995
S250TIM R/W Step 250 Time Period (min) Real 420997
S250AEP R/W Step 250 Analog End Point Real 420999
Timer Function Block Configurations
Code
R/W Description Range Register (MB)
DYT01T R/W Delay Timer 01 Time (min) Real 421001
OST01T R/W One Shot Timer 01Time (min) Real 421003
RCT01NT R/W Rept Cy Timer 01 ON Time (min) Real 421005
RCT01FT R/W Rept Cy Timer 01 OFFTime (min) Real 421007
ROT01T R/W Retentive On Timer 01 Time (min) Real 421009
.................................................................................................................................................................................
DYT21T R/W Delay Timer 21 Time (min) Real 421201
OST21T R/W One Shot Timer 21Time (min) Real 421203
RCT21NT R/W Rept Cy Timer 21 ON Time (min) Real 421205
RCT21FT R/W Rept Cy Timer 21 OFFTime (min) Real 421207
ROT21T R/W Retentive On Timer 21 Time (min) Real 421209
