Maintenance UM353-1
April 2012
10-8
DISPLAYED
CODE
LINK/MODBUS
CODE (Hex/Dec)
DESCRIPTION
A3 DEV None Alarm A3 Deviation
A3 OR None Alarm A3 Overrange
A4 HI None Alarm A4 High
A4 LO None Alarm A4 Low
A4 HI D None Alarm A4 High Deviation
A4 LO D None Alarm A4 Low Deviation
A4 DEV None Alarm A4 Deviation
A4 OR None Alarm A4 Overrange
B1 HI None Alarm B1 High
B1 LO None Alarm B1 Low
B1 OR None Alarm B1 Out of Range
B2 HI None Alarm B2 High
B2 LO None Alarm B2 Low
B2 OR None Alarm B2 Out of Range
B3 HI None Alarm B3 High
B3 LO None Alarm B3 Low
B3 OR None Alarm B3 Out of Range
B4 HI None Alarm B4 High
B4 LO None Alarm B4 Low
B4 OR None Alarm B4 Out of Range
Emeg Man None Emergency Manual
Em Local None Emergency Local
Standby None Standby Sync
Override None Override
EMERG OR None Emergency Override - PCOM block
INTRLK None Interlocked – PCOM block
DFAIL None Device Failed – PCOM block
MAX LOOP None Maximum Loop Size
S HI Lim None Setpoint HI Limit
S LO Lim None Setpoint LO Limit
U1 Status None User Status #1
U2 Status None User Status #2
ATUNE W1 None Autotuner Warning: hys/desamp >0.2; see Section 8.3 for ‘W#’ details
ATUNE W2 None Autotuner Warning: Deviation Ratio is HI; see Autotune procedure
ATUNE W3 None Autotuner Warning: Avg. Deviation is LO; see Autotune procedure
ATUNE E1 None Autotuner Error: limit cycle timeout
ATUNE E2 None Autotuner Error: process out of range
ATUNE E3 None Autotuner Error: Only applies when % HYS set to A. Process too noisy.
E In RAM None Insufficient Volatile Memory Available
E In Con None Insufficient Constant Memory Available
E Db CRC None Database CRC/Checksum Error
E P Qual None Poor I/O quality
AIEnn NU None AIEnn Function Block Not Updating
CIEnn NU None CIEnn Function Block Not Updating
DIEnn NU None DIEnn Function Block Not Updating
