UM353-1B Model Designation and Specifications
April 2012
13-7
Type ‘B’ Thermocouple:
Range Limits...................................-18°C to 1815°C (0°F to 3300°F)
Performance Range.........................800 to 1815°C
Accuracy .........................................+/-0.7°C
Conformity......................................<= 0.06°
Software Output Type.....................Analog (configurable °C, °F, °R, °K)
Ambient Temperature Effect: ........+/- 0.15°C/°C
Type ‘N’ Thermocouple:
Range Limits...................................-200°C to 1300°C (-325°F to 2370°F)
Performance Range.........................0 to 1300°C
Accuracy .........................................+/-0.5°C
Conformity......................................<= 0.06°
Software Output Type.....................Analog (configurable °C, °F, °R, °K)
Ambient Temperature Effect: ........+/- 0.10°C/°C
Type DIN 43760/ IEC 751 RTD (à = 0.003850):
Range Limits...................................-185°C to 622°C (-300°F to 1152°F)
Accuracy .........................................+/-0.4 °C
Software Output Type.....................Analog (configurable °C, °F, °R, °K)
Ambient Temperature Effect: ........+/- 0.04°C/°C
Type US (NBS126) RTD (à = 0.003902):
Range Limits...................................185°C to 613°C (-300°F to 1135°F)
Accuracy .........................................+/-0.4°C
Software Output Type.....................Analog (configurable °C, °F, °R, °K)
Ambient Temperature Effect: ........+/- 0.04°C/°C
Type JIS C-1604 RTD (à = 0.003916):
Range Limits...................................-185°C to 610°C (-300°F to 1130°F)
Accuracy .........................................+/-0.4°C
Software Output Type.....................Analog (configurable °C, °F, °R, °K)
Ambient Temperature Effect: ........+/- 0.04°C/°C
Slidewire
Resistance Range ............................500-5000 Ω
Software Output Type.....................Analog (% slidewire 0.0 to 100.0)
Accuracy: ........................................+/- 0.1%
Ambient Temperature Effect: ........+/- 0.01°C/°C
Ohms
Resistance Range ............................0-5000 Ω
Software Output Type.....................Analog (ohms)
Accuracy: ........................................+/- 0.1%
Ambient Temperature Effect: ........+/- 0.01°C/°C
Millivolt
Narrow Range .................................-19.0 to 19.0 mVdc
Accuracy .........................................+/-5.0 uV
Ambient Temperature Effect ..........1.0 uV/°C
Wide Range.....................................-30.0 to 77 mVdc
Accuracy .........................................+/-8.0 uV
Ambient Temperature Effect ..........2.5 uV/°C
Software Output Type.....................Analog (millivolts)
Overvoltage.....................................See Table on next page
