Function Blocks UM353-1B
April 2012
3-18
Table 3-7 Input Types, AINU Block
# ENGineering UNITS
AVAILABLE ON INPUT TYPES
1 Deg C (degrees Celsius)
JT/C, KT/C, TT/C, ET/C, ST/C, RT/C, BT/C, NT/C, DRTD, URTD, JRTD
2 Deg F (degrees Fahrenheit)
JT/C, KT/C, TT/C, ET/C, ST/C, RT/C, BT/C, NT/C, DRTD, URTD, JRTD
3 Deg R (degrees Rankine)
JT/C, KT/C, TT/C, ET/C, ST/C, RT/C, BT/C, NT/C, DRTD, URTD, JRTD
4 K (Kelvin)
JT/C, KT/C, TT/C, ET/C, ST/C, RT/C, BT/C, NT/C, DRTD, URTD, JRTD
****** 6 Character ASCII
OHM, SLW, NMV, WMV
Table 3-8 Calibration Input Values, AINU Block
# TYPE DESCRIPTION OPERATING RANGE FIELD CAL ‘FLD’
POINTS
1 JT/C Type J Thermocouple
-185°C to 1100°C (-300°F to 2010°F) 0°C & 800°C
2 KT/C Type K Thermocouple
-185°C to 1370°C (-300°F to 2500°F) 0°C & 1000°C
3 TT/C Type T Thermocouple
-200°C to 370°C (-400°F to 698°F) -100°C & 300°C
4 ET/C Type E Thermocouple
-185°C to 1000°C (-300°F to 1830°F) 0°C & 800°C
5 ST/C Type S Thermocouple
-18°C to 1650°C (0°F to 3000°F) 400°C & 1400°C
6 RT/C Type R Thermocouple
-18°C to1610°C (0°F to 2930°F) 400°C & 1400°C
7 BT/C Type B Thermocouple
-18°C to 1815°C (0°F to 3300°F) 800°C & 1600°C
8 NT/C Type N Thermocouple
-185°C to 1300°C (-300°F to 2370°F) 0°C & 1000°C
9 DRTD DIN 43760/IEC 751 RTD
alpha 0.003850
-185°C to 622°C (-300°F to 1152°F) 100Ω (0°C) &
280.98Ω (500.0°C)
10 URTD US (NBS 126) RTD
alpha 0.003902
-185°C to 613°C (-300°F to 1135°F) 100Ω (0°C) &
283.36Ω (500.0°C)
11 JRTD JIS C-1604 RTD
alpha 0.003916
-185°C to 610°C (-300°F to 1130°F) 100Ω (0°C) &
285Ω (502.94°C)
12 OHM* Resistance
0Ω to 5000Ω 0Ω & 5000Ω
13 SLW* Slidewire
500Ω to 5000Ω
Field cal not available
14 NMV Narrow Millivolt - 19.0 mV to 19.0 mV 0 mV & +15 mV
15 WMV Wide Millivolt -30.0 mV to 77 mV 0 mV & +75 mV
• Not available in Model 352Plus.
Table 3-9 SEN MIN/MAX and MIN/MAX SCALE Parameters, AINU Block
SEN TYPE (1) SEN MIN SEN MAX MIN SCALE MAX SCALE
1-12,14,15 [min. operating
value]
[max. operating
value]
[min. range scale
value]
[max. range scale
value]
13 0 (%) 100 (%) 0.0 PRCT (2) 100.0 PRCT (2)
Note:
(1) When changing SEN TYPE, type number should blink after pressing STORE. Use STEP UP and then STEP
DOWN to verify that sensor type has changed.
(2) Range scaling of the AINU output when the Slidewire sensor type is selected can be accomplished using a SCL_
Scaler function block connected to the output (O1) of the AINU function block.
