LOGO! Manual
A5E00067781 01
96
Description of function
Each seven-day time switch has three setting cams, each
of which can be used to configure a time window. You use
the cams to set the on and off times for the time windows.
At the on times, the seven-day time switch activates the
output if it is not already on.
At the off times, the seven-day time switch deactivates the
output if it is not already off. If you set an on time on one
cam that is the same as the off time on another cam on the
seven-day time switch, then the on and off times conflict. In
such cases, cam 3 has priority over cam 2 and cam 2 has
priority over cam 1.
Parameter assignment window
The parameter assignment window for cam no. 1, for ex-
ample, is as follows:
B01:No1
D=MTWTFSS+
On =06:30
Off=08:00
On time (06.30 hours)
See the section ”Displaying/
hiding parameters – type of
protection” on page53
Off time (08.00 hours)
Block B01
Cam No 1
Weekdays (daily)
Day of the week
The letters after “D=” have the following meanings:
M : Monday (Monday)
T : Tuesday (Tuesday)
W : Wednesday (Wednesday)
T : Thursday (Thursday)
F : Friday (Friday)
S : Saturday (Saturday)
S : Sunday (Sunday)
LOGO! Functions
