97
LOGO! Manual
A5E00067781 01
An uppercase letter means the weekday has been se-
lected. A ”–” means the weekday has not been selected.
Switching times
You can set any time between 00:00 and 23:59.
––:–– means no switching on or off.
Setting the seven-day time switch
To enter the switching times, proceed as follows:
1. Position the cursor on one of the time switch’s cam (No)
parameters (e.g. No1).
2. Press OK. LOGO! opens the parameter assignment
window for the cam. The cursor is positioned on the day
of the week.
3. Use the and keys to select one or more days of the
week.
4. Use the key to move the cursor to the first position for
the on time.
5. Set the on time.
Use the and keys to change the value. To move the
cursor from one position to another, use the and
keys. You can only select the value ––:–– at the first
digit (––:–– means no switching operation).
6. Use the key to move the cursor to the first position for
the off time.
7. Set the off time (same procedure as for step 5).
8. Conclude your input by pressing OK.
The cursor is positioned at parameter No 2 (cam 2).
You can now parameterize another cam.
Note
Please refer to the technical specifications in Section 4.3.2
for information regarding the accuracy of the time switch.
LOGO! Functions
