LOGO! Manual
A5E00067781 01
200
LOGO! 12/24RC
LOGO! 12/24RCo
LOGO! 12RCL
Line length (unshielded) 100 m 100 m
Analog inputs
Number 2 (I7, I8)
Range 0 ... 10 V DC
Max. input voltage 28.8 V DC
Digital outputs
Number 8 4
Output type Relay outputs Relay outputs
Electrical isolation Yes Yes
In groups of 2 1
Activation of digital input Yes Yes
Output voltage
Output current
Continuous current I
th
(per
connector)
Max. 10 A Max. 10 A
Incandescent lamp load
(25,000 switching cycles) at
1000 W 1000 W
Fluorescent tubes with electr.
control gear (25,000 switch-
ing cycles)
10 x 58 W 10 x 58 W
Fluorescent tubes, conven-
tionally compensated (25,000
switching cycles)
1 x 58 W 1 x 58 W
Fluorescent tubes, uncom-
pensated (25,000 switching
cycles)
10 x 58 W 10 x 58 W
Short circuit–proof and over-
load–proof
Short–circuit current limitation
Technical Specifications
