201
LOGO! Manual
A5E00067781 01
LOGO! 12/24RC
LOGO! 12/24RCo
LOGO! 12RCL
Derating None throughout
the entire tempera-
ture range
None throughout
the entire tempera-
ture range
Short circuit–proof cos 1 Power protection
B16
600A
Power protection
B16
600A
Short–circuit proof cos 0.5 to
0.7
Power protection
B16
900A
Power protection
B16
900A
Parallel switching of outputs
to increase power
Not permitted Not permitted
Protection of output relay (if
desired)
Max. 16 A,
characteristic B16
Max. 16 A,
characteristic B16
Switching rate
Mechanical 10 Hz 10 Hz
Electrical
Ohmic load/lamp load 2 Hz 2 Hz
Inductive load 0.5 Hz 0.5 Hz
Technical Specifications
