Primer: S7-300 Programmable Controller, Quick Start
C79000-G7076-C500-01
The program status is only displayed for the area visible to the editor.
Netzwerk 1:
RLO STA STANDARD
A( 0 1 0
A( 0 1 0
O I 0.0 0 0 0
O I 0.1 0 0 0
)010
AT 6 01 0
O M 0.0 0 0 0
)010
AN T 5 0 0 0
= M 0.0 0 0 0
RLO STA STANDARD
AN M 0.0 1 0 0
= Q 0.7 1 1 0
Network 2 : Green phase for vehicles
Network 1:
Detecting green request for pedestrians
Figure 7-3 Example of Displaying the Program Status in STL
And that’s it. That’s how quickly you get
successful results as promised with our
S7-300:
an executable user program in STL!
Displaying the
Program Status in
STL
