Analog value representation
4.3 Measuring ranges
2AI TC ST analog electronic module (6ES7134-4JB00-0AB0)
22 Manual, 04/2007, A5E01076883-01
Measuring range for thermocouple Types R, S
Table 4-9 SIMATIC S7 format: Type R, S measuring range in °C
Units
Type R, S in °C
Decimal Hexadecimal
Range
> 2019,0 32767 7FFF
H
Overflow
2019,0
:
1769,1
20190
:
17691
4EDE
H
:
451B
H
Overrange
1769,0
:
-50,0
17690
:
-500
451A
H
:
FE0C
H
Nominal range
-50,1
:
-170,0
-510
:
-1700
FE0B
H
:
F95C
H
Underrange
< -170,0 -32768 8000
H
Underflow
Measuring range for thermocouple Type T
Table 4-10 SIMATIC S7 format: Type T measuring range in °C
Units
Type T in °C
Decimal Hexadecimal
Range
> 540,0 32767 7FFF
H
Overflow
540,0
:
400,1
5400
:
4001
1518
H
:
0FA1
H
Overrange
400,0
:
-270,0
4000
:
-2700
0FA0
H
:
F574
H
Nominal range
< -270,0 -32768 8000
H
Underflow
