Parameter List 09.02
5-22 Siemens AG 6SE7087-6AK85-1AA0
Rectifier/Regenerating Unit Operating Instructions
PNU
* : Conf.
Par.
OP1S parameter name
Description
Value range
[phys. unit]
Selection text
Display
Indices
Factory-
setting
See
Modify
(access /
status)
P587
*
Src Master/Slave
Source for the master/slave drive changeover (control word 2, bit 27)
0: Master drive: The control works with an internal current setpoint
1: Slave drive: The control works with an external current setpoint
Other values: see allowed settings in Section 4.3.1.1 (process data
wiring of the control word)
B/R parameter
PNU=24BHex; Type=L2; Scaling: 1Hex
=
∧
1
0 to 6005 2
(0)
2/ BR
2/ BR
P588
*
Src No Ext Warn1
Source of the 'External warning 1' message (control word 2, bit 28)
0: Not allowed
1: No external warning
Other values:
see allowed settings in Section 4.3.1.1 (process data wiring of
the control word)
B/R- parameter
PNU=24CHex; Type=L2; Scaling: 1Hex
=
∧
1
1 to 6005 2
(1)
3/ BR
3/ BR
P589
*
Src No Ext Warn2
Source of the 'external warning 2' message (control word 2, bit 29))
0: Not allowed
1: No external warning
Other values: see allowed settings in Section 4.3.1.1 (process data
wiring of the control word)
B/R parameter
PNU=24DHex; Type=L2; Scaling: 1Hex
=
∧
1
1 to 6005 2
1
3/ BR
3/ BR
P590
*
Src Base/Reserve
Source of the 'Base / reserve settings' switching command (control word 2,
bit 30)
0: Base setting
1: Reserve setting
1005: Binary input 5 of the CUR board
Other values: see allowed settings in Section 4.3.1.1 (process data
wiring of the control word)
No base/reserve changeover possible
PNU=24EHex; Type=L2; Scaling: 1Hex
=
∧
1
0 to 6005 -
1005
3/ BR
3/ BR
P591
*
Src ContactorMsg
Source of the 'Main contactor energized' message(control word 2, bit 31)
0: Not allowed
1: No main contactor checkback signal
1001 to 1005: CUR terminals
4101 to 4116: SCB-SCI1- terminals (serial I/O)
4201 to 4216: SCB-SCI2- terminals (serial I/O)
For details see Section 4.3.1.1
Notes:
If the function is active, pulses are released as soon as the message is
available.
No base / reserve settings possible
PNU=24FHex; Type=L2; Scaling: 1Hex
=
∧
1
1 to 4216 -
1
3/ BR
3/ BR
