Siemens 6SE7032-2EE85-1AA0 User Manual

09.02 Parameter List
Siemens AG 6SE7087-6AK85-1AA0
5-23
Rectifier/Regenerating Unit Operating Instructions
PNU
* : Conf.
Par.
OP1S parameter name
Description
Value range
[phys. unit]
Selection text
Display
Indices
Factory-
setting
See
Modify
(access /
status)
r599 CW/SW 12-Pulse
Display of control/status word for 12-pulse mode, bit 0 to 15, see Section
3.8.4.
6
7
14
15
2
3
10
11
0
1
8
9
4
5
12
13
PNU=257Hex; Type=V2; Scaling: 1Hex
=
∧
1
- 2/ BR
P600
*
Trg Bit Ready On
Destination of the status bit 'ready for turn ON' (status word 1, bit 0)
Power is ON, the drive may be turned on.
Depending on the selected index all settings according to Section 4.3.1.2
(process data wiring of the status word) may be selected.
i01: GG: selection of a base drive terminal
i02: SCI : selection of a SCI1/2 terminal
PNU=258Hex; Type=L2; Scaling: 1Hex
=
∧
1
0 to 4212 2
0
3/ BR
3/ BR
P601
*
Trg Bit Rdy Oper
Destination of the status bit 'Ready for operation' (status word 1, bit 1)
All the settings specified in Section 4.3.1.2 (process data wiring of the status
word) are permissible, depending on the index selected
Parameter values, indices: as P600
PNU=259Hex; Type=L2; Scaling: 1Hex
=
∧
1
0 to 4212 2
0
3/ BR
3/ BR
P602
*
Trg Bit Operat
Destination of the status bit 'Run' (status word 1, bit 2)
The unit is in operation.
Parameter values, indices: as P600
PNU=25AHex; Type=L2; Scaling: 1Hex
=
∧
1
0 to 4212 2
0
2/ BR
2/ BR
P603
*
Trg Bit Fault
Destination of the status bit 'Fault' (status word 1, bit 3)
Note:
For issuing the fault message via a terminal the active status (bit has H-
level) is inverted (broken wire proof).
Parameter values, indices: as P600
PNU=25BHex; Type=L2; Scaling: 1Hex
=
∧
1
0 to 4212 2
i001=1002
i002=0
2/ BR
2/ BR
P604
*
Trg Bit No OFF2
Destination of the status bit 'No OFF2 command' (status word 1, bit 4)
Parameter values, indices: as P600
PNU=25CHex; Type=L2; Scaling: 1Hex
=
∧
1
0 to 4212 2
0
3/ BR
3/ BR
P606
*
Trg BitONblocked
Destination of the status bit 'Turn-ON locked' (status word 1, bit 6)
Note:
For issuing the message via a terminal the active status (bit has H-level) is
inverted (broken wire proof).
Parameter values, indices: as P600
PNU=25EHex; Type=L2; Scaling: 1Hex
=
∧
1
0 to 4212 2
0
3/ BR
3/ BR
