09.02 Parameter List
Siemens AG 6SE7087-6AK85-1AA0
5-25
Rectifier/Regenerating Unit Operating Instructions
PNU
*
: Conf.
Par.
OP1S parameter name
Description
Value range
[phys. unit]
Selection text
Display
Indices
Factory-
setting
See
Modify
(access /
status)
P618
*
Trg Current Lim.
Destination wiring of the status bit "Current limit active"
(status word 2, bit 18)
Note:
For issuing the message via a terminal the active status (bit has H-level) is
inverted (broken-wire proof).
Parameter values, indices: as P600
PNU=26AHex; Type=L2; Scaling: 1Hex
=
∧
1
0 to 4212 2
0
3/ BR
3/ BR
P619
*
Trg Bit Ext Flt1
Destination of the status bit 'External fault 1' (status word 2, bit 19)
Note:
For issuing the message via a terminal the active status (bit has H-level) is
inverted (broken wire proof).
Parameter values, indices: as P600
PNU=26BHex; Type=L2; Scaling: 1Hex
=
∧
1
0 to 4212 2
0
3/ BR
3/ BR
P620
*
Trg Bit Ext Flt2
Destination of the status bit 'External fault 2'
(status word 2, bit 20)
Note:
For issuing the message via a terminal the active status (bit has H-level) is
inverted (broken wire proof).
If an ON command is active, L-level causes fault trip after 200 msec.
Parameter values, indices: as P600
PNU=26CHex; Type=L2; Scaling: 1Hex
=
∧
1
0 to 4212 2
0
3/ BR
3/ BR
P621
*
Trg Bit ExtWarn
Destination of the status bit 'External warning'
(status word 2, bit 21)
Note:
For issuing the message via a terminal the active status (bit has H-level) is
inverted (broken wire proof).
Parameter values, indices: as P600
PNU=26DHex; Type=L2; Scaling: 1Hex
=
∧
1
0 to 4212 2
0
3/ BR
3/ BR
P622
*
Trg Bit i2t Inv
Destination of the status bit 'Warning unit overload'
(status word 2, bit 22);
Note:
For issuing the message via a terminal the active status (bit has H-level) is
inverted (broken wire proof).
Parameter values, indices: as P600
PNU=26EHex; Type=L2; Scaling: 1Hex
=
∧
1
0 to 4212 2
0
3/ BR
3/ BR
P623
*
Trg BitFltTmpInv
Destination of the status bit 'Fault unit overtemperature'
(status word 2, bit 23
Note:
For issuing the message via a terminal the active status (bit has H-level) is
inverted (broken wire proof).
Parameter values, Indices: as for P600
PNU=26FHex; Type=L2; Scaling: 1Hex
=
∧
1
0 to 4212 2
0
3/ BR
3/ BR
