Connection 09.02
3-4 Siemens AG 6SE7087-6AK85-1AA0
Rectifier/Regenerating Unit Operating instructions
Function Terminal Connected load / Description
Incoming supply terminals X1-U1/L1
X1-V1/L2
X1-W1/L3
See Technical Data
Chapter 14
Protective conductor PE/GND
Power feedback terminals
autotransformer/system
X4-1U2/1T1
X4-1V2/1T2
X4-1W2/1T3
See Technical Data
Chapter 14
Power terminals
DC link voltage
(inverter)
X1-C/L+
X1-D/L-
See Technical Data
Chapter 14
Fan terminals
Sizes E, H, K
X19-1
X19-2
Supply connection for fan
230V AC ±10%, 50 to 60 Hz ±5%
Size E
Current consumption: 0.84A
Size H
Current consumption: at 50 Hz: 2.6 A, at 60 Hz: 3.3 A
Size K
Current consumption: at 50 Hz: 5.2 A, at 60 Hz: 6.6 A
Table 3.1 Power connections
Sizes C and E
Terminal X19 fused with fuse (F3 and F4):
T2A/250V time-lag 6.3x32 mm (¼“ x 1¼“)
(19343-T2A/250V Messrs. Wickmann-Werke GmbH or 0034.5231 FST Messrs. Schurter)
or
T2A/250V time-lag 5x20 mm
(19198-T2A/250V Messrs. Wickmann-Werke GmbH or 0034.3993 FSD Messrs. Schurter)
Sizes H and K
Terminal X19 fused with fuse (F3 and F4):
T2A/250V time-lag 6.3x32 mm (¼“ x 1¼“)
(19343-T7A/250V Messrs. Wickmann-Werke GmbH or 0034.5243 FST Messrs. Schurter)
WARNING
If the device is operated on a network in which a phase is grounded instead of the
neutral, the plant operator must ensure that fans (terminals X19-1, X19-2) and the main
contactor circuit (terminals X9-4, X9-5) are fed from this phase and the neutral.
If it is not possible to ensure this, the fans and main contactor circuit must be fed from an
isolating transformer.
Moreover, the feed to terminals X19-1, X19-2, X9-4, X9-5 must be implemented via an
isolating transformer if:
● The connection between the protective ground and electronic ground is interrupted
(see Chapter 3.3.3 Terminals on the CUR Module).
● The rectifier/regenerating unit is operated in an ungrounded network.
