Parameter List 09.02
5-10 Siemens AG 6SE7087-6AK85-1AA0
Rectifier/Regenerating Unit Operating Instructions
PNU
*
: Conf.
Par.
OP1S parameter name
Description
Value range
[phys. unit]
Selection text
Display
Indices
Factory-
setting
See
Modify
(access /
status)
5.5 Hardware configuration
P090
*
Board Position 2
PCB in position 2 (right) of the electronic box
0 = No optional PCBs
1 = CB Communication Board
2 = TB Technology Board
3 = SCB Serial Communication Board
Description for Setting:
Only the following combinations of PCBs and positions are admitted:
Position 3(P091) Position 2(P090)
- CB
- TB
- SCB
SCB CB
CB TB
SCB TB
CB SCB
PNU=5AHex; Type=O2; Scaling: 1Hex
=
∧
1
0 to 3
none
CB
TB
SCB
-
0
3/ HBR
3/ H
P091
*
Board Position 3
PCB in position 3 (center) of the electronic box
Description see P090(PCB position 2)
PNU=5BHex; Type=O2; Scaling: 1Hex
=
∧
1
0 to 3
Text as for P090
-
0
3/ HBR
3/ H
