Siemens 6SE7038-2EH85-1AA0

09.02 Parameter List
Siemens AG 6SE7087-6AK85-1AA0
5-19
Rectifier/Regenerating Unit Operating Instructions
PNU
* : Conf.
Par.
OP1S parameter name
Description
Value range
[phys. unit]
Selection text
Display
Indices
Factory-
setting
See
Modify
(access /
status)
P556
*
Src2 OFF2
Source 2 of the 'OFF2' command (control word 1, bit 1)
Description see P555
B/R Parameter
PNU=22CHex; Type=L2; Scaling: 1Hex
=
∧
1
1 to 6005 2
1
2/ BR
2/ BR
P557
*
Src3 OFF2
Source 3 of the 'OFF2' command (control word 1, bit 1)
Description see P555
B/R Parameter
PNU=22DHex; Type=L2; Scaling: 1Hex
=
∧
1
1 to 6005 2
1
2/ BR
2/ BR
P561
*
Src InvRelease
Source for the "Run enable" command (control word 1, bit 3)
0: Pulse inhibit
1: Automatic "Run enable" at end of waiting times
Other values: see allowed settings in Section 4.3.1.1 (process data
wiring of the control word)
B/R Parameter
PNU=231Hex; Type=L2; Scaling: 1Hex
=
∧
1
1 to 6005 2
(1)
2/ BR
2/ BR
P565
*
Src1 Fault Reset
Source 1 of the 'Reset' command (control word 1, bit 7)
0: No source selected
1: Not allowed
1003: Binary input 3 of the CUR board
Other values: see allowed settings in Section 4.3.1.1 (process data
wiring of the control word) whereby "Reset" from the
PMU is always possible
Note: The "Acknowledge" control command is edge-triggered
B/R parameter
PNU=235Hex; Type=L2; Scaling: 1Hex
=
∧
1
0 to 6005 2
(i001=0)
(i002=1003)
2/ BR
2/ BR
P566
*
Src2 Fault Reset
Source 2 of the 'Reset' command (control word 1, bit 7)
Description see P565
B/R parameter
PNU=236Hex; Type=L2; Scaling: 1Hex
=
∧
1
0 to 6005 2
(0)
2/ BR
2/ BR
P567
*
Src3 Fault Reset
Source 3 of the 'Reset' command (control word 1, bit 7)
Description see P565
B/R parameter
PNU=237Hex; Type=L2; Scaling: 1Hex
=
∧
1
0 to 6005 2
(2001)
2/ BR
2/ BR
P568
*
Src Jog1 ON
Source of the 'Jog 1' command (control word 1, bit 8)
0: No Jog operation
1: Not allowed
Other values: see allowed settings in Section 4.3.1.1 (process data
wiring of the control word)
B/R-Parameter
PNU=238Hex; Type=L2; Scaling: 1Hex
=
∧
1
0 to 6005 2
0
2/ BR
2/ BR
