Siemens 72G Series User Manual

s
________________________________________________________________________________
Siemens Energy & Automation, Inc. 3333 Old Milton Parkway Alpharetta, GA 30202
4
Starter Selection
Table 1: In Delta, 200 – 460 Volt starter ratings
HP @
200V
HP @
230V
HP @
460V
Rated
Current
(Amps)
Overload
Range
(Amps)
Current Limit
Range
(Amps)
Manufacturer
Catalog
Number
5 7.5 15 22 7 - 27 26 – 94 72EG34AFP
7.5 10 25 35 12 - 44 41 - 148 72GG34AFP
10 15 30 42 14 - 53 49 - 179 72HG34AFP
15 20 40 55 18 - 69 64 - 234 72JG34AFP
20 25 50 68 22 - 85 79 - 289 72KG34AFP
25 30 60 80 26 - 100 93 - 340 72LG34AFP
30 40 75 105 35 - 131 121 - 447 72MG34AFP
40 50 100 130 43 - 163 151 - 553 72NG34AFP
50 60 125 156 52 - 196 181 - 663 72PG34AFP
In Delta
Configuration
75 100 - 252 83 - 315 292 - 1071
72RG32AFP
Table 2: In Delta, 460 - 575 Volt starter ratings
HP @
460V
HP @
575V
Rated
Current
(Amps)
Overload
Range
(Amps)
Current Limit
Range
(Amps)
Manufacturer
Catalog
Number
15 20 22 7 - 27 26 - 94 72EG35AFP
25 30 35 12 - 44 41 - 148 72GG35AFP
30 40 42 14 - 53 49 - 179 72HG35AFP
40 50 55 18 - 69 64 - 234 72JG35AFP
50 60 68 22 - 85 79 - 289 72KG35AFP
60 75 80 26 - 100 93 - 340 72LG35AFP
75 100 105 35 - 131 121 - 447 72MG35AFP
100 125 130 43 - 163 151 - 553 72NG35AFP
In Delta
Configuration
125 150 156 52 - 196 181 - 663
72PG35AFP
