Step 10: View Meter Data
Use the softkeys to select which data to display. Use the left and right arrow
buttons to scroll through the available display screens.
Display Screens
Additional display screens for the 9610 (with EN50160 option):
Softkey Contents
V, I , P F Volts, Amps, Power Factor
Volts Volts
Amps Amps
Power Tota l Po w er
Energy1 Energy delivered
Demand1 Demand delivered
Pk Dmd1 Peak Demand delivered
V Bar, I Bar, P Bar Voltage, Current and Power Bar Graphs
Summary1, Summary2 Volts/Amps Summary, Power Summary
V-Trend, I-Tre nd, P-Trend Voltage, Current, Power Trends
D Inputs Digital Inputs
DI - I/O Digital I/O on expansion I/O card
D-Output Digital Outputs
Anlg - I/O Analog In and Out
Phasors Phasors
Name Plt Nameplate information
Events Events
Setpoint Setpoint
Energy2 Energy received
Demand2 Demand received
Pk Dmd2 Peak Demand received
THD Volts and Amps Total Harmonic Distortion
V1 Harm, V2 Harm,... V1, V2, V3, V4 harmonics
I1 Harm, I2 Harm,... I1, I2, I3, I4, I5 harmonics
TOU Time Of Use Active Rate / Season
TOU Egy TOU Energy delivered
TOU Dmd1 & TOU Dmd2 TOU Peak Demand 1 and 2
Avblty Power Availability
Softkey Contents
PQ Freq Power Quality Power Frequency
PQ Vmag1 PQ Supply Voltage 1
PQ Vmag2 PQ Supply Voltage 2
PQ Flk1 PQ Flicker 1
PQ Flk2 PQ Flicker 2
PQ Vdist PQ Voltage Disturbance
PQ Vunb PQ Voltage Unbalance
PQ Vhrm1 PQ Voltage Harmonics 1
PQ Vhrm2 PQ Voltage Harmonics 2
