5
9510 / 9610 Models
Integrated Display Model
Comes with front optical port.
TRAN (transducer) Model
The TRAN model has no display.
Remote Terminal Unit (RTU)
The RTU (9510 only) has no power metering capability.
Available Options
Notes
1
Standard = password protected, no locking or sealing.
2
RMANSI = ANSI C12.16 approved; meets ANSI C12.20 class 0.2
accuracy standards.
Option
Form Factor Current Inputs COM I/O Security
Model
9510
Integ. Display
TRAN
5 MB memory
10 MB memory
Up to 256
sampling rate
Standard
(5 Amp)
1 Amp
Current
probes
Standard (RS-232,
RS-485, optical)
Ethernet RJ45
Ethernet Fiber
Modem
Standard (8 digital
inputs, 3 Form C relays,
4 Form A outputs)
Extra 8 digital inputs
Four 0-1mA analog
inputs
Four 0-20 mA analog
inputs
Four -1 to 1mA analog
outputs
Four 0-20 mA analog
outputs
Standard
1
RMANSI
2
Power Supply
Standard
Low Voltage
DC
9610
Form Factor Current Inputs COM I/O Security
Integ. Display
TRAN
5 MB memory
10 MB memory
Up to 512
sampling rate
(standard)
1024 sampling
rate (optional)
EN50160
compliance
Same as
9510
Same as
9510
Same as 9510 Same as
9510
Power Supply
Same as
9510
9510
RTU
Form Factor Current Inputs COM I/O Security
Integ. Display
TRAN
5 MB memory
10 MB memory
N/A Same as
9510
Same as 9510 Standard
only
Power Supply
Same as
9510
