ACUSON Freestyle User Manual 5-13
Scanning
B-Mode Scanning
The default scanning mode for the system is B-Mode.
NOTE: Functions listed in the Tools menu will vary depending on how the System
Administration / User Selected Keys are congured.
B-Mode Tools
The real-time Control Bar Tools Soft Key displays a number of secondary-level real-time
imaging-related controls. The active Tools items will vary according to the scanning mode.
Press the Tools button to display the Tools options. When this list is active, the Rotary knobs
will control interaction with the list. Use the knobs in the same manner as is used to control the
real-time control bar. The outer knob moves up and down the list and the inner knob adjusts
the value or state for individual items.
B-Mode Tools Sub-Menu
B-Mode Tools Sub-Menu Description
Exit Tools Exits the Tools sub-menu.
PostProc Post Processing. Adjusts the gray scale curves of the B-mode
image. Lower values will have softer appearance, higher values will
have a more “contrasty” appearance.
Displayed in the on-screen settings window as PP.
Dyn. Range Image Dynamic Range. Displayed in decibels (dB).
Displayed in the on-screen settings window as numerical units
followed by dB.
Compound Spatial Compounding. Selects different levels of spatial
compounding. Spatial compounding combines different scan steering
angles to improve image quality.
Displayed in the on-screen settings window as SC.
Speckle Speckle Filter. Applies image lters that remove speckle or enhance
edges. In general, higher values will apply more ltering for potentially
smoother image appearance.
Displayed in the on-screen settings window as SF.
L/R Reverse Left/Right Reverse. This switches the orientation of the image on the
screen so that the index marker symbol display is moved from the left
of the image to the right of the image.
M-Line Displays a dotted line through the middle of the image with depth
markers.
Needle Visualization Improves the display of needles during procedures. See below for
details.
Wide Widens the image of linear probes.
