ACUSON Freestyle User Manual 5-15
Scanning
Color Flow Mode Scanning
Pressing Color on the real-time Control Bar activates color ow mapping mode. This key
switches color ow on and off.
In color ow mode the real-time controls include:
C Gain – Color Gain controls the color ow overall gain.
C Box – Color Box controls the up/down position of the color ow box.
Color Flow Tools
The real-time Control Bar Tools Soft Key displays a number of secondary-level real-time
imaging-related controls. The active Tools items will vary according to the scanning mode.
Press the Tools button to display the Tools options. When this list is active, the Rotary knobs
will control interaction with the list. Use the knobs in the same manner as is used to control the
real-time control bar. The outer knob moves up and down the list and the inner knob adjusts
the value or state for individual items.
Color Flow Mode Tools Sub-Menu
Color Flow Mode
Tools Sub-Menu Description
Exit Tools Exits the Tools sub-menu.
Color Map Steps through multiple color ow maps. This selection also allows you to move from
velocity mode to power mode.
They are displayed in the on-screen settings window as either Vel (velocity maps) or Pwr
(Amplitude Power maps). The maps are represented in the color bar next to the real-time
image.
Vel Invert Velocity Invert. Shifts the color map orientation from the default of red = towards the
transducer, to blue = towards the transducer. When invert is selected, the color map
graphic bar will invert.
Displayed in the on-screen settings window as Vel.
WARNING: It is important to pay careful attention to the color ow invert
status of the system. The non-inverted state is red=towards the transducer,
displayed at the top of the color bar and blue=away from the transducer,
displayed at the bottom of the color bar.
Priority Adjusts the arbitration that takes place between B-Mode tissue signals and Color Flow
mapping signals. Higher priority settings will give greater weight to color ow signals. This
can be used with weaker ows or to ll in ow near vessel borders.
Displayed in the on-screen settings window as Pri.
C Persist Color Persistence. Increases or decreases the amount of persistence applied to Color
Flow signals. Higher settings will produce a smoother looking image and may help with
weak ow, but may have an appearance of lower frame rates.
Displayed in the on-screen settings window as CP.
C Filter Color Filter. Adjusts the Color Flow high pass lter. Lower settings will pass through
lower frequency ow signals.
Displayed in the on-screen settings window as CF.
C Scale Color Scale. Increases or decreases the Color Flow pulse repetition frequency. The
scale is displayed next to the color bar in centimeters per second.
