Examples and HowTos
A31003-S2000-M102-3-76A9, 08/07/2009
4-20 Asterisk - OpenStage Family, Administration Manual
beispiele.fm
An LLDP-Med Example
7. Click on to create the second dial plan rule.
8. Enter the following data:
Summary: When 0 is entered as first digit, the phone will wait 1 second. After this, 0 will be
sent to the server, which might result in a call to an operator, for instance. When further
digits are entered during the 1 second timespan, the next dial plan rule will take control.
9. Click on to create the third dial plan rule.
Parameter Value Description/Remarks
Digit string 0 This rule matches numbers beginning with 0. In the
USA, this number calls the operator.
Action C When Minimum length, Maximum length, and the
length of the digit string entered by the user match, the
Timer is started. When it expires, the digits are sent to
the server. When another digit is entered before expiry,
the next dial plan entry will come into operation.
Minimum length 1 This rule matches numbers with a length of 1 digits.
Maximum length 1
Timer 1 The phone waits 1 second for further digits. If the user
does not enter any further digits, the action specified in
Action is initiated.
