CMR Installation and Operation Manual | Issue: July 2021, Revision 01.0
32
6 Operation (continued)
6.4 Operations counter
Only the controller pole of a multi-phase recloser is fitted with an electromechanical
counter mounted on the underside of the device adjacent to the position indicator.
The counter increments each time a close operation occurs.
Figure 28: Counter and LED
Figure 27: Operation of non-reclose handle
