S7-300 Automation System, Hardware and Installation: CPU 31xC and CPU 31x
A5E00105492-03
6-9
 /DEHOWKHPRGXOHV
$VVLJQLQJVORWQXPEHUV
After installation, you should assign a slot number to each module. This makes it
easier to assign the modules in the configuration table in 67(3. The table below
shows the slot number assignment.
Table 6-4 Slot numbers for S7 modules
6ORWQXPEHU 0RGXOH 5HPDUNV
1 Power supply (PS) –
2 CPU –
3 Interface module (IM) To the right of the CPU
4 1st signal module To the right of the CPU or IM
5 2nd signal module –
6 3rd signal module –
7 4th signal module –
8 5th signal module –
9 6th signal module –
10 7th signal module –
11 8th signal module –

