Siemens CU240B-2 Installation Manual

Technical data
6.6 690 V converters
Power Module PM240-2
102 Hardware Installation Manual, 01/2020, A5E33294624B AL
Table 6- 32 PM240-2, IP20, frame size D, 500 V … 690 V 3 AC
Article No. - without filter
Article No. - with filter
6SL3210-1PH22-7UL0
6SL3210-1PH22-7AL0
6SL3210-1PH23-5UL0
6SL3210-1PH23 -5AL0
6SL3210-1PH24-2UL0
6SL3210-1PH24-2AL0
LO base load power 22 kW 30 kW 37 kW
LO base load input current 25 A 33 A 40 A
LO base load output current 27 A 35 A 42 A
HO base load power
18.5 kW
22 kW
30 kW
HO base load input current
24 A
28 A
36 A
HO base load output current 23 A 27 A 35 A
Siemens fuse according to IEC
Fuse according to UL, class J
3NA3817-6KJ (40 A)
35 A
3NA3820-6KJ (50 A)
45 A
33NA3822-6 (63 A)
60 A
Power loss without filter
0.60 kW
0.77 kW
0.93 kW
Power loss with filter
0.60 kW
0.78 kW
0.94 kW
Required cooling air flow
55 l/s
55 l/s
55 l/s
Weight without filter
17.4 kg
17.4 kg
17.4 kg
Weight with filter
18.9 kg
18.9 kg
18.9 kg
Table 6- 33 PM240-2, IP20, frame size E, 500 V … 690 V 3 AC
Article No. - without filter
Article No. - with filter
6SL3210-1PH25-2UL0
6SL3210-1PH25-2AL0
6SL3210-1PH26-2UL0
6SL3210-1PH26-2AL0
LO base load power
45 kW
55 kW
LO base load input current
50 A
59 A
LO base load output current
52 A
62 A
HO base load power
37 kW
45 kW
HO base load input current
44 A
54 A
HO base load output current 42 A 52 A
Siemens fuse according to IEC
Fuse according to UL, class J
3NA3824-6 (80A)
80 A
3NA3824-6 (80A)
80 A
Power loss without filter
1.07 kW
1.30 kW
Power loss with filter 1.08 kW 1.31 kW
Required cooling air flow 83 l/s 83 l/s
Weight without filter
27.1 kg
27.1 kg
Weight with filter
28.5 kg
28.5 kg
