Siemens CU240B-2 Installation Manual

Technical data
6.2 Ambient conditions
Power Module PM240-2
Hardware Installation Manual, 01/2020, A5E33294624B AL
75
6.2 Ambient conditions
Property
Version
Ambient conditions for transport in the transport packaging
Air-conditioning - 40° C … + 70° C, according to Class 2K4 to EN 60721-3-2:1997
maximum humidity 95% at 40 °C
Mechanical system Shock and vibration permissible according to 1M2 to IEC 60721-3-2:1997
Chemical substances Protected according to Class 2C2 to IEC 60721-3-2:1997
Biological ambient condi-
tions
Suitable according to Class 2B1 to IEC 60721-3-2:1997
Ambient conditions for long-term storage in the product packaging or in transport packaging
Air-conditioning
- 25 °C … + 55° C, according to Class 1K3 to IEC 60721-3-1:1997
Chemical substances
Protected according to Class 1C2 to IEC 60721-3-1:1997
Biological ambient condi-
tions
Suitable according to Class 1B1 to IEC 60721-3-1:1997
Ambient conditions in operation
Installation altitude Up to 1000 m above sea level without limitations
Restrictions for special ambient conditions (Page 105)
Air-conditioning
1)
• FSA ... FSC ambient operating temperature
2)
– For operation according to Low Overload: -10 °C … +40 °C
– For operation according to High Overload: -10 °C … +50 °C
– Restrictions for special ambient conditions (Page 105)
• FSD ... FSG ambient operating temperature
2)
– For operation according to Low Overload: -20 °C … +40 °C
– For operation according to High Overload: -20 °C … +50 °C
–
Restrictions for special ambient conditions (Page 105)
• Relative humidity: 5 … 95%, condensation not permitted
• Oil mist, ice formation, condensation, dripping water, spraying water, splashing water
and water jets are not permitted
Mechanical system Vibration test during operation according to IEC 60068-2-6 Test Fc (sinusoidal)
• 0 ... 57 Hz: 0.075 mm deflection amplitude
• 57 ... 150 Hz: 1 g acceleration amplitude
• 10 frequency cycles per axis
Shock test according to IEC 60068-2-27 Test Ea (half-sine)
• 5 g peak acceleration
• 30 ms duration
• 3 shocks in all three axes in both directions
Chemical substances
• FSA … FSC: Protected according to 3C2 to IEC 60721-3-3:2002
• FSD … FSG: Protected according to 3C3 to IEC 60721-3-3:2002
Biological ambient condi-
tions
Suitable according to 3B1 to IEC 60721-3-3: 2002
Pollution
Suitable for environments with degree of pollution 2 according to EN 61800-5-1
