Siemens CU240B-2 Installation Manual

Technical data
6.5 400 V converters
Power Module PM240-2
Hardware Installation Manual, 01/2020, A5E33294624B AL
95
Table 6- 26 PM240-2, PT, frame size E, 380 V … 480 V 3 AC
Article No. without filter
Article No. with filter
6SL3211-1PE31-1UL0
6SL3211-1PE31-1AL0
LO base load power 55 kW
LO base load input current 104 A
LO base load output current 110 A
HO base load power
45 kW
HO base load input current
94 A
HO base load output current 90 A
Fuse according to IEC
Fuse according to UL, class J
3NA3836 (160 A)
150 A
Power loss without filter
1.65 kW
1)
Power loss with filter
1.67 kW
1)
Required cooling air flow
83 l/s
Weight without filter
30.5 kg
Weight with filter
32 kg
1)
Approx. 1.4 kW through the heatsink
Table 6- 27 PM240-2, IP20, frame size F, 380 V … 480 V 3 AC
Article No. without filter
Article No. with filter
6SL3210-1PE31-5UL0
6SL3210-1PE31-5AL0
6SL3210-1PE31-8UL0
6SL3210-1PE31-8AL0
6SL3210-1PE32-1UL0
6SL3210-1PE32-1AL0
LO base load power
75 kW
90 kW
110 kW
LO base load input current
140 A
172 A
198 A
LO base load output current
145 A
178 A
205 A
HO base load power
55 kW
75 kW
90 kW
HO base load input current
117 A
154 A
189 A
HO base load output current 110 A 145 A 178 A
Fuse according to IEC
Fuse according to UL, class J
3NA3140 (200 A)
200 A
3NA3142 (224 A)
250 A
3NA3250 (300 A)
300 A
Power loss without filter
1.91 kW
2.46 kW
2.28 kW
Power loss with filter 1.93 kW 2.48 kW 2.30 kW
Required cooling air flow 153 l/s 153 l/s 153 l/s
Weight without filter
58 kg
58 kg
62 kg
Weight with filter
64 kg
64 kg
66 kg
