1 Introduction
Thank you for buying a KS 50-1 TCont.
This expert line unit offers special functions for tempering and hot-runner
equipment. An optional 20mA current loop or an RS485/422 interface are
available for easy connection of peripheral units including a KS 50-1 TCont to a
machine control system.
The protocol is widely used in the plastics industry and supported by many
injection moulder and extruder manufacturers, e.g. Arburg, Engel and
Krauss-Maffei. Another name for it is ”ARBURG protocol”.
This operating note describes the extended functions and features of
KS 50-1 TCont. For all other functions, refer to operating manual
9499-040-62811 for KS 50-1 Industrial Controller.
1.1 Definitions
A current loop interface transmits serial data by switching on and off a 20mA
current in a conductor loop at the data bit clock. During the rest condition, or
during transmission of ”1” bits, a constant 20 mA current is flowing, whilst the
current flow is intermittent with ”0” bits.
Another name for 20mA current loop interface is TTY interface
(TeleTYpe(writer)).
l
Caution! The unit contains ESD-hazarded components.
ARBRUG is a registered trademark of ARBURG GmbH + CO, D-Loßburg.
.
Introduction
Operating note KS 50-1 TCont 3 Definitions
