Periphery board (250p) FCI2016
1
9 |
Building Technologies
Element Des. Function
Fuses F301 30 A fuse for battery
F302 Fuse 20 A for voice alarm DC 24 V output
Indicators H1301 Status display for circuit card 1 (circuits 1 and 2)
Adjustment elements S100 Reset key for periphery processor (without circuits)
Jumpers X403 Degraded mode ALARM SILENCEABLE/NON SILENCEABLE
X602 Degraded mode ENABLE/DISABLE NAC 1 class A or NAC 1-1 class B
X603 Degraded mode ENABLE/DISABLE NAC 1-2 class B
X604 NAC 1 class A/B selection
X605 NAC 1 class A/B selection
X606 NAC 1 class A/B selection
X305 Power supply 2 ON/OFF
Connector X201 Peripheral data bus to the PMI & mainboard
X202 Peripheral data bus output
X204 Future extension (not used)
X301 Connector for power supply 1 (PS1)
X302 Connector plug for power supply 2 (PS2) in housing (3HU)
X303 Battery connection
X304
DC 24 V connection to Card Cage VCA2002 for feed to the voice alarm
modules and associated peripherals
X601 NAC1 output
X801 BELL follower input
X901 NAC 2 extension or releasing module
X902 Leased line / city tie module
X1001 Output DC 24 V AUX
X1101 Plug block for relay connections
X1302 For future application
X1401 Detector circuit circuit card 1, circuit 1
X1402 Detector circuit circuit card 1, circuit 2
