5.19.2 Connection diagram for collective detector line
General
Connect a control panel-specific end-of-line (EOL) to the end of the collective
detector line.
Connecting external alarm indicators
Observe the following points when connecting external alarm indicators:
● If the external alarm indicator is connected to only one detector, there is no
limitation.
● If the detector FDOOT241-A9 is used in combination with the base adapter
FDB299, there is no limitation.
● If the external alarm indicator is connected to more than one detector, this is
only admissible on the following conditions:
– All detectors use the Sinteso base FDB20x (do not mix with older base
generations e.g. AlgoRex bases).
– No sounder base is used.
– The detectors have a part number and the product version in question (see
table).
Part number
Device version (REV)
External alarm indicator connected
to several collective detectors
FDOOT241-9
A5Q00004813 <13
1
Not admissible
A5Q00004813 ≥30
1
Permissible
2
A5Q00015955 13 ≤ES <30 Permissible
2
FDOOT241-A9
S54310-F11-A1 ≥30 Permissible
2
1
This also applies to the flame detector FDF2x1-9 and the linear smoke detector FDL2x1-9
2
The cabling of the external alarm indicators can be migrated to FDnet without any changes.
