3BPlanning
28BDefault settings
4
69 |
138
Building Technologies
007004_t_en_--
Fire Safety
2015-11-04
4.5.2.2 Specifications
No.
Name
Operating
temperature
typ. / max.
Static activation
temperature
1
Differential activation
temperature
2
Differential activation possible
from ambient temperature:
[°C]
[°C]
∆T [K]
[°C]
1 A1R
60 °C rate of rise
25 / 50 60 25 3
2 BR
80 °C rate of rise
40 / 65 80 29 30
1
Applicable with slow temperature increases <1 K/min.
2
Applicable with fast temperature increases of >10 K/min. When there is a slow temperature
increase of <10 K/min, this value rises by a few degrees.
All parameter sets meet the criteria of standard EN 54-5.
4.6 Default settings
The detector operates in the default parameter set as long as the control panel has
not assigned a valid parameter set to the detector.
The following table shows the default parameter set of the various fire detectors.
Fire detector
Default parameter set
FDOOT241-x/-Ax
in FDnet mode High Compensation
FDOOT241-9
in collective mode:
● Sensor mode 0 (neural fire detector) ES <13 = Insensitive
ES ≥13 = High Compensation
● Sensor mode 1 (heat detector) A1R
● Sensor mode 2 (smoke detector) Universal
FDOOT241-A9
in collective mode:
● Sensor mode 0 (neural fire detector) High Compensation
● Sensor mode 1 (heat detector) A1R
● Sensor mode 2 (smoke detector) Universal
FDOOT241-A3
in AnalogPLUS mode:
● As DO1131A Sensitive
● As DOT1131A Fast Response
● As DT1131A A1R
● As DT1132A BS
FDOOT241-A4
in SIGMALOOP mode:
● In SIGMALOOP mode the sensor evaluation
takes place in the control panel
-
