Siemens FD20 User Manual

2BStructure and function
22BAccessories
3
48
| 138
Building Technologies
007004_t_en_--
Fire Safety
2015-11-04
3.7.7 Collective sounder base FDSB292
● For acoustic alarming in the case of an event
● For the collective detector line
● Gray terminal block
● With two micro terminals
● For the recess-mounted cable entry
● For surface-mounted cable entry, up to 6 mm cable
diameter
● Compatible with:
● Not compatible with:
● For details, see document 009769
● Order no.: A5Q00013755
See also
 Applicable documents [➙ 9]
3.7.8 Base attachment FDB291
● For the surface-mounted cable entry, as of 6 mm cable
diameter
● Compatible with:
● Order no.: A5Q00001603
See also
 Base attachment FDB291 [➙ 80]
3.7.9 Base attachment wet FDB295
● For mounting in humid, wet environments and if the
detector heating unit is used
● Maximum protection category achievable: IP54
● Six break-out points for M20 x 1.5 metal cable glands
● Compatible with:
● Order no.: S54319-F21-A1
See also
 Base attachment wet FDB295 [➙ 81]
