133 |
2015-11-04
8.4 Dimensions
FDB201/FDB201-AA FDB202/FDB222
FDB221/FDB221-AA
Figure 5: Dimensions with detector bases at distance or directly attached
1
Suitable for surface-mounted
cables up to Ø 6 mm
3
Detector base directly attached to
the mounting surface
2
Detector base at a distance
8.5 Environmental compatibility and disposal
This equipment is manufactured using materials and procedures which
comply with current environmental protection standards as best as
possible. More specifically, the following measures have been
undertaken:
● Use of reusable materials
● Use of halogen-free plastics
● Electronic parts and synthetic materials can be separated
Larger plastic parts are labeled according to ISO 11469 and ISO 1043.
The plastics can be separated and recycled on this basis.
Electronic parts and batteries must not be disposed of with domestic
waste.
● Take electronic parts and batteries to local collection points or
recycling centers.
● Contact local authorities for more information.
● Observe national requirements for disposing of electronic parts
and batteries.
