4.3.4 Neural fire detector FDOOT221
4.3.4.1 Description
Parameter sets:
Standard (2)
The parameter set is intended for robust response. It is particularly suited to
application in rooms where deceptive phenomena such as cigarette smoke or dust
can be expected.
Standard Plus (4)
The parameter set is fast and highly sensitive. It is particularly suited to application
in rooms without deceptive phenomena where the priority is on detecting the fire
early.
4.3.4.2 Use
No.
Name
Risk of damage
to persons
Value
concentration
Room geometry
Deceptive
phenomena
Risk of fire
Critical fire size
Low…
High
Low…
High
Simple…
Complex
Few…
Many
Low…
High
Low…
Medium
2 Standard
4 Standard Plus
4.3.4.3 Specification
No.
Name
Optical
Thermal
Response time
Sensitivity, open
fire
Sensitivity,
smoldering fire
Static activation
temperature
Differential activation
temperature
[s]
[%/m]
[%/m]
[°C]
∆T [K]
2 Standard 64 3.2 11.4 80 29
4 Standard Plus 50 2.3 8 80 25
1
Applicable with fast temperature increases >10 K/min.
All parameter sets meet the criteria of standard EN 54-7.
