3-4 OPERATION
FIREFINDER-XLS INSTALLATION, OPERATION AND MAINTENANCE MANUAL | CHAPTER 3
Menu Press the Menu button (see q
above) to display a menu of all
PMI/PMI-2/PMI-3 options. See
Figure 3-5. The currently available
options are described below.
The alternate language is
only visible/present if the Zeus
programming tool has set the
PMI/PMI-2/PMI-3 for two languages
- a base language and an alternate
language.
ALERT MODE When an event occurs in the system, the display enters the Alert or Firefighter’s
mode automatically. The events are displayed in priority order (as shown in the table
below), the local audible sounds and the appropriate LED blinks. If the event caused
notification appliances to sound, the Audibles On indicator lights. At the bottom of
the screen an Acknowledge soft key is displayed. Pressing this key acknowledges
the event and silences the local audible. A Silence Audibles soft key is displayed at
the bottom of the screen. Once all events are acknowledged and audibles are
silenced, a Reset System soft key becomes available in the lower right side of the
display. If Fire notification appliances were active, two additional soft keys become
available at the bottom of the screen. These allow the operator to silence or unsilence
the notification appliances (audibles). When fire notification appliances are silenced
the Audibles Silenced LED lights. A separate user-configured LED on an SCM-8,
LCM-8, or LVM is required for indicating the silenced state for notification appliances
used for MNS purposes.
Press the More Info/+ button to display a screen showing details relating to the
selected event. Additional soft keys appear at the bottom of this screen, including one
that displays a map of the area in which the event occurred, provided this information
has been programmed using the Zeus tool. The operator can return to the previous
screen by pressing the (–) or ESC button, which is adjacent to the More Info/+ button.
Unlike the PMI, which displays a fixed set of four event queues on the Alert screen
(Alarm, Supervisory, Security, and Trouble), the PMI-3 and PMI-2 version 12 and above
support the display of up to nine event queues. The following table shows the default
and configurable event types by Country mode.
naidanaC
)edomycageL-noN(
ASU
)edomycageL-noN(
-/eporuE
aisA
cificaP
ycageL
edom
*1SNM*1SNMMLAmralA
MLAMLALBTyrosivrepuS
*2SNM*2SNMytiruceS
GME*SAGelbuorT
PUSPUS
GDLBCES
LBTLBT
*TSNM*TSNM
**HTO
delbanefI*
elbarugifnocresU**
Figure 3-5
PMI Menu Screen
Alert
Report
Maint
10:53
Category text information
Logout
Diagnostics
Lamp Test
Alt. Language*
Press any lit green arrow key to continue.
Press “?” for more help information.
ALERT: Firefighter’s Mode, view events.
REPORT: View/Print event and system info.
MAINT: Control devices and inputs/outputs.
FUNCTION KEYS: Execute logic commands.
LOGOUT: Leave password protected area.
DIAGNOSTICS: For factory use only.
LAMP TEST: 30 second PMI LED test.
Function Keys
Menu
FireFighter@1
To Next Page
