OPERATION 3-9
CHAPTER 3 | FIREFINDER-XLS INSTALLATION, OPERATION AND MAINTENANCE MANUAL
Supervisory When a supervisory is detected, the yellow Supervisory LED blinks, the System’s
internal audible pulses, and the event(s) display on the screen with a blinking exclama-
tion mark (!). This event listing displays the Event Custom Message, the Time of the
event occurrence and the Supervisory Event Category (i.e., Security, Sprinkler, etc.). In
addition, the System responds to supervisories with other output functions (as
programmed in the Zeus tool).
An Acknowledge Supervisory soft key displays in the bottom left corner of the
screen. Press this key to acknowledge each supervisory and to silence the local
audible. The blinking exclamation point (!) then changes to a check mark (9).
Trouble When a trouble is detected, the yellow Trouble LED blinks, the System’s internal
audible pulses, and the event(s) display on the screen with a blinking exclamation
mark (!). This event listing displays the Event Custom Message, the Time of the event
occurrence and the Trouble Event Category (refer to the Trouble Event: Category
Cross Reference Table below).
ECNEREFER-SSORCYROGETAC:TNEVEELBUORT
yrogetaCeciveDlacisyhP
ECIVED tiucric/enozro,poolCLMroMPV,CLDanoecivedtupnidesivrepusynA
dnaIRTH,11-TPFH,
149HOO,144CTOODF,11-PFH,.e.i-troperelbuort
61-MIS,MCO,SMH,secivedIRT,11-TPF,11-PF,secived224OICDF
.stiucricdesivrepusyllaudividni
ENOZsenoz6B1-/1-MZC,senozMZH,senozMAZ,senozCAZ,senozCIZ
ELUDOM ,CIZ,MPV,CLM,CL
D,3-IMP/2-IMP/IMP,.e.i-elbuorteludomdesivrepusynA
.CIN,XSP,CSP,MAZ
METSYS cificepsaotdetniopniptoneratahtseruliaf/elbuortdetaler-metsySynA
.ecivedroenoz,eludom
KROWTENTENH/TENX
.elbatcelesdleiftoneradnayrotcaf
ehtybdenifed-erperaseirogetacesehtfollA:ETON
In addition, the System responds to troubles with other output functions (as pro-
grammed in the Zeus tool).
An Acknowledge Trouble soft key displays in the bottom left corner of the screen.
Press this key to acknowledge each trouble and to silence the local audible. The
blinking exclamation point (!) then changes to a check mark (9). See Figure 3-6.
If acknowledged troubles remain in the queue, the system will sound the local
audible every 24 hours as a reminder. A message will appear on the PMI/PMI-2/PMI-
3 and the sounder will remain on until it is silenced.
Reset Procedures There are two types of reset procedures that can be performed on the FireFinder-XLS
System: Hard Reset and Soft Reset.
Hard Reset Other terms for Hard Reset are Power-up, Initialization, and Cold Reset. Applying
power to the system performs a Hard Reset. Doing so initializes the entire system.
What Is Lost:
• All event conditions (Alarm, supervisory, etc. provided they have returned to
the normal state).
• Arm/disarm.
• Manual sensitivity adjustment.
