FS-250 PROGRAMMING MANUAL
3
The Operator Interface
Interface for User and Maintenance Levels
The operator interface for configuring and programming the FS-250 uses the 4 line
by 20 character LCD display, the M1 through M4 buttons on the left and right of the
display and sixteen push buttons at the bottom of the interface. User Level and
Maintenance Level utilize the LCD display and the four buttons (two on each side of
the display) to navigate and alter the basic operation of the panel. The display will
show messages in the four corners of the display that will be adjacent to the four
buttons M1 through M4. The message on the display adjacent to the button
indicates the action that will occur when the button is pressed. So pressing M1 will
cause the function labeled as “Menu 1” to be pressed.
M1 M3
M2 M4
For example, in the following figure, menu item 1 (Lamp Test) is described as having
an Action of ‘Run Lamp Test’. If the button next to Lamp Test is depressed, Lamp
Test will be performed. Menu item 2 (View History) will cause the first event in the
event history to be displayed on the screen.
Action: Run Lamp Returns to the top of
the list or to the level
up
Will display panel go to the next screen
History
Lamp Test Esc
View
History More
Menu 1 Menu 3
Menu 2 Menu 4
To Next Page
